Feature |
Description |
|
Maximum Channels |
Up to 64 IP cameras. |
|
Support IP cam |
A-MTK H.265, H.264 |
|
Audio Codec |
G.726 / G. 711 |
|
Resolutions |
QVGA / VGA / SXGA / FULL HD 30fps @ all resolutions |
|
Audio |
Volume adjustable / Mute Two way audio |
|
Live Preview |
Support 1 / 4 /16/ 32/ 64 division Full-screen Snapshot Selectable display cameras |
|
Digital Zoom /ePTZ |
Google earth like digital zoom |
|
PTZ |
Support PTZ cameras PTZ / Preset / Tour / Auto pan / Iris / Focus /Speed Add / Remove /Goto preset |
|
Record |
Support HDD capacity up to 6TB capacity Recording video by schedule/motion detection/ DI User defined auto recycle recording (First In First Out) |
|
Playback |
Support 1 / 4 /16 division Play / Reverse / Pause / Seek / Pre- I frame / Next Frame Speeds: 1/4 , 1/2 , 1 , 2 , 4 , 8 , 16 , 32 Volume control Convert to AVI |
|
Multi-Language |
Multi-language selectable English / Traditional Chinese / German / Greece / Tai |
|
User Interface |
3 styles UI user selectable. Graphic UI |
|
Event Detection |
Motion / Disconnect / HDD / Schedule trigger TCP notify (from RJ45 LAN ) Schedule-able Event Detection NVR external DI box IP camera DI trigger |
|
Alarm Event |
Display on Screen / Record / Snapshot / E-Mail / TCP / HTTP / FTP NVR external DO box IP camera DO event |
|
Notification |
SMTP / HTTP / FTP / TCP Address Book management |
|
User authentications |
User management Function permissions |
|
Camera setting |
DVR like(auto setting) Auto Search Profile selectable |
|
Schedule setting |
Graphical interface Weekly schedule |
|
Network |
Fix IP / DHCP / PPPOE / DIPS Report / UPNP transversal |
|
System time |
Manual setting NTP support DST support |
|
Motion detection |
Detection windows setting (Max 10 windows) Sensitivity adjust |
|
Snapshot |
Preview snapshot in HDD or Remove-able device Search Event Snapshot Backup snapshot to remove-able device |
|
Disk Management |
S.M.A.R.T. hard-disk detection Partition management Format partition Samba management |
|
Maintenance |
Resolution selectable , 1024x768 / 1280x1024 / 1366x768 / 1440x900 / 1920x1080 Display style select-able, Normal / Simple / Professional / Advance Screen adjustment, Brightness / Contrast / Saturation / Hue Reset default Backup / Restore setting Firmware upgrade System Restart |
|
Remote |
Internet Explorer™ 8 or above Fully function remote live preview Fully function remote playback Support low bit-rate connection with live preview and playback Selectable camera connection |
